HIGHLIGHTS
- Four-wheel suspension
- Ajustable tiller
- USB port
- LED light package with directional signals
- Control panel with LCD screen
- Rear-view mirrors
- Two cup holders
- Foldable removable basket
- Tires with inner tube
- Hand brake
Available options
- Lockable rear and/or front compartments
- Cell phone holder
- Safety belt
- Bluetooth sound bar
FEATURES
| S-DriveTM controls | 120 A |
| Traction | Rear |
| Batteries | 2 x Gr. 22 – 50 Ah |
| Off-board charger | 8 A |
| Speed control | Yes |
| Electromagnetic brake | Yes |
| Adjustable tiller | Dual |
| Colours | Matte Blue or Cabernet |
| Seat colour | Black |
TECHNICAL SPECIFICATIONS
| Weight capacity | 350 lb (160 kg) |
| Overall width | 23.6″ (600 mm) |
| Overall length | 53″ (1345 mm) |
| Maximum speed | 8.7 mph (14 km/h) |
| Ground clearance | 3.5″ – 5.9″ (90 mm – 150 mm) |
| Turning radius | 74″ (1880 mm) |
| Tires | 4 x 12″ (4 x 305 mm) |
| Standard seat | 18″ x 18″ (455 mm x 455 mm) |
LIMITED WARRANTY
5 years: Main frame, seat post, steering structure and fork.
2 years: Motor/transaxle assembly, electromagnetic brake, controller, charger, electrical cables, and other electronic components.
1 year: Original batteries and Bluetooth sound bar.
EXCLUSIONS
Other than manufacturing defects, this warranty does not apply to parts requiring replacement for normal wear and tear such as plastic parts, motor brushes, brake pads, fuses and light bulbs, tires and inner tubes, seat, and upholstery.
More details on the warranty can be found in the Owner’s Manual. Customers are responsible for labor and shipping costs.
